FUJIKURA-FSM-88R Ribbon Fusion Splicer Splicing Machine with CT50 Fiber Cleaver.
FUJIKURA-FSM-88R
The Fujikura FSM-88R is a high-performance ribbon fusion splicer designed for fast, reliable, and low-loss splicing of optical fiber ribbons. It supports ribbon fiber splicing for telecommunications networks, FTTH/FTTx installations, backbone networks, and high-capacity fiber optic infrastructure.The FSM-88R features replaceable V-grooves and supports both 200 µm and 250 µm fiber spacing with compatible accessories. Its automatic functions, touchscreen interface, and intelligent fusion control help improve splicing efficiency and maintain consistent splice quality in field applications.
Package Accessories:
- Ribbon Fusion Splicer FSM-88R
- Optical Fiber Cleaver CT-50
- Ribbon Fiber Stripper RS03
- Battery Pack BTR-15
- AC Adapter ADC-20
- AC Power Cord ACC-15
- USB Cable USB-01
- Fusion Splicer Strap ST-02
- Electrodes ELCT2-16B
- Hexagonal Wrench HEX-01
- V-Groove Cleaning Brush VCB-01
- Carrying Case CC-30
- Carrying Case Strap ST-03
- Alcohol Dispenser AP-02
- Quick Reference Guide QRG-03-E
- Fiber Holder FH-70-12
Fujikura FSM-88R – Technical Details
| Specification | Details |
|---|---|
| Brand | Fujikura |
| Model | FSM-88R |
| Description | Ribbon Fiber Optic Fusion Splicer |
| Automation Type | Fully Automatic |
| Fiber Count | Up to 12 ribbon fibers |
| Made in | Japan |
| Splicing Time | Approx. 11–12 seconds (SM FAST mode) |
| Heating Time | Approx. 13–15 seconds (single 60 mm sleeve mode) |
| Electrode Life | Approx. 1,500 splices |
| Battery Capacity | Approx. 165 splice and heat cycles per charge |
| Display | 5-inch TFT colour LCD touchscreen |
| Dimensions (W × D × H) | Approx. 170 × 173 × 150 mm |
| Item Weight | Approx. 2.6 kg (including battery) |
| Splice Loss | Approx. 0.05 dB for ITU-T G.652 fibre |
